Horizontal Fast Wire Cutting Mchine

+
  • 水平环刀机21.jpg
  • 水平环刀机1.jpg

Revolving CNC Cutting Machine Cutting Method: Loop Knife Can Cut material: sponge, sponge laminated materials Advantage: Max. Cutting Speed: 80m/min


Category:

Revolving Contour Cutting

Products

Foam Machine

Revolving Contour Cutter

Horizontal Revolving Contour Cutter----- Horizontal Revolving Contour Cutter with Rotary Table

ming@dtfirm.com

Description

Model DTC-R2012V DTC-R2012V5 DTC-R2012H
Max. Product Size L2800*W2200*1000mm L3000*W2200*H1200mm L2800*W2200*H1000mm
Control System Industrial Computer+Window XP Industrial Computer+Window XP Industrial Computer+Window XP
Software D&T revolving Profiler D&T revolving Profiler D&T revolving Profiler
Cutting Speed 0~40m/min(Adjustable) 0~40m/min(Adjustable) 0~40m/min(Adjustable)
Tolerance ±5mm ±5mm ±5mm
Total Power 5kw,380V,50Hz 5kw,380V,50Hz 5kw,380V,50Hz
Overall Weight 2500kg 2700kg 2500kg
Overall Dimension L6000*W5630*3000mm L6200*W5630*3200mm L6000*W5630*3000mm

Revolving CNC Cutting Machine

Cutting Method: Loop Knife

Can Cut material: sponge, sponge laminated materials

Advantage: Max. Cutting Speed: 80m/min
