Description

Oscillating Blade Contour Cutter

TECHNICAL DATA
Type DTC-S1212 DTC-S2012 DTC-S2512
Max. Product Size 2500*1200*1000(mm) 2500*2000*1200(mm) 2500*2500*1200(mm)
Cutting Line 1.3~1.5mm
Control System Industrial    Computer
Software D&T    Profiler
Cutting Speed 0~6m/min
Person ±1mm
Power <5.5kw <6.5kw <8.5kw
Vacuum De-dust Included Included Included
Overall Weight 1200kg 1500kg 2200kg
Overall Dimension 6200*2400*2380mm 6200*3200*2800mm 6200*3800*2800mm

Oscillating Blade Contour Cutter

Cutting Method: Oscillating baled

Can Cut material: sponge, EVA, foaming rubber

Advantage: No dust with smooth cutting surface
