Carrousel Foam Cutting Machine
ThiscutteradoptstheadvancedFrequencyconversionsystem.Automaticnumbercontrolled.Itisoperationishandyandcuttingisexact.Thismachineissuitabletocuthorizontalsheetforseveralspongeonce.Itcontrolbydigitalsystem,andFrequencyconversionsystem. CarrouselFoamCuttingMachine ModelDTYQ-750DTYQ-850DTYQ-1150Max.ProductSizeL2000*W1500*H1200mm(4pcs)L2000*W1500*H1200mm(5pcs)L2000*W1500*H1200mm(8pcs)Max.CuttingFoamSizeL2000*W1500*H1200mm(4pcs)L3000*W2150*H1200mm(3pcs)L4500*W2150*H1200mm(3pcs)CuttingThickness2-150mm2-150mm2-150mmBladeLength8940mm10000mm10240mmWorktableTurningSpeed0-3.5r/min0-3.0r/min0-2.0r/minWorkTableDiameter6m7.3m10.5mTotalPower8.04kw8.04kw10.24kwOverallWeight3300kg3500kg3800kgOverallDimensionL6900*W6000*H2400mmL7900*W7000*H2400mmL11500*W11000*H2400mm
Category：
Products
Carrousel Foam Cutting Machine
Description
This cutter adopts the advanced Frequency conversion system. Automatic number controlled. It is operation is
handy and cutting is exact. This machine is suitable to cut horizontal sheet for several sponge once. It control by
digital system, and Frequency conversion system.
| Carrousel Foam Cutting Machine | |||
| Model | DTYQ-750 | DTYQ-850 | DTYQ-1150 |
| Max.Product Size | L2000*W1500*H1200mm(4 pcs) | L2000*W1500*H1200mm(5 pcs) | L2000*W1500*H1200mm(8 pcs) |
| Max.Cutting Foam Size | L2000*W1500*H1200mm(4 pcs) | L3000*W2150*H1200mm(3 pcs) | L4500*W2150*H1200mm(3 pcs) |
| Cutting Thickness | 2-150mm | 2-150mm | 2-150mm |
| Blade Length | 8940mm | 10000mm | 10240mm |
| Worktable Turning Speed | 0-3.5r/min | 0-3.0r/min | 0-2.0r/min |
| Work Table Diameter | 6m | 7.3m | 10.5m |
| Total Power | 8.04kw | 8.04kw | 10.24kw |
| Overall Weight | 3300kg | 3500kg | 3800kg |
| Overall Dimension | L6900*W6000*H2400mm | L7900*W7000*H2400mm | L11500*W11000*H2400mm |
